Equipment Moving Trailer
42', 48' and 53' Tandem or Tridem
EZ-2-LOAD, built to go to work
EZ-2-LOAD Equipment Trailers have greatly simplified the loading and unloading of equipment, while increasing operator efficiency and safety. Add high quality construction, materials and components to the mix and you have a dynamic industry leader. EZ-2-LOAD Equipment Trailers are designed to meet the unique needs of the discerning user who is looking for the best return on their investment by increasing the safety and efficiency of their work environment.
Introducing the most innovative Equipment Moving trailers available today
This trailer is designed to handle almost any type of equipment, tracked or wheeled or any combination of. The operator's dream is made a reality for an affordable price. Utilizing the unique air-assisted ramps, loading and unloading is performed efficiently and safely.
Features and Benefits
- Unique air ramps
- No heavy ramps to lift
- Efficient loading and unloading
- Increased productivity and safety
- Lower operating costs
- Quality built for rugged environments
- Exceptional durability
- Superior baked-on finish
- Premium return on your investment
Available Options
- Inset aluminum ramps for access to upper deck
- Toolbox (45" x 18" x 18") + brackets
- Winch track/winches/J hooks/straps
- In-floor flush mounted D-Rings
- Side mount D-Rings
- LED light package
- Wide load lights (pullout style)
- Ez-2-Load paint color: Red, Yellow
- Aluminum wheel package
- Tire carrier
- Keruing filled 45" x 72" in lieu of self-cleaning ramps
- City light package on wood filled ramps
- 114" in width
In conjuction with continuous product improvements, BWS Manufacturing Ltd. reserves the right to make changes to products described and/or illustrated herein without notice or liability. Prices subject to change without notice.
42', 48' AND 53' TANDEM OR TRIDEM
Standard Specifications
| Overall Length | 42'/48'/53' Nominal |
|---|---|
| Overall Width | 102" |
| Weight (lbs) | 12,240/13,320/15,900(+/-296) |
| Gooseneck | |
| Length | 10' 6" |
| Coupling | 24" |
| Coupler Height | 48" |
| Coupler Plate | 5/16" Hi-tensile |
| Cross Members | Hi-tensile l-beam @ 16 in. OC |
| Deck | |
| Length | 25'/31'/35' nominal |
| Main Beam | 3/8" x 5", 100 KSI top and bottom flanges |
| Side Rail | 6' @ 8.2 channel |
| Cross Members | Hi-tensile standard l-beam @ 12' OC on lower deck |
| Loaded Height | 35" nominal |
| Beavertail | 6' nominal @ 8 degree |
| Landing Gear | Holland Mark V 120,000 lbs. |
| Mud Flaps | Standard |
| Floor | 1 1/8" Shiplapped Apitong/Keruing outside the main beam on lower deck 1 1/8" shiplapped softwood between main beams on lower deck and in gooseneck 3/16" formed deck plate over wheels |
| Axels/Suspension | |
| Suspension | Ridewell 25,000 lbs 6.5" ride 61" spread |
| Axels | 22,500 lbs/77" |
| ABS | 2S1M |
| Brake Chambers | #3030, all axles |
| Camshafts | 28 spline non-enclosed |
| Hubs & Drums | 8 stud unimount c/w cast drums |
| Rims | 6.75" x 17.5 steel disc wheels |
| Tires | 235/75R 17.5 18 ply |
| 5' Flip Neck | |
| Electrical | |
| Electrical System | Modular weather proof lighting system |
| Front Connector | SAE J560 7 Pin |
| Regulations | Meets Canadian and US regulations |
| Finishing | |
| Paint | Steel shot blasted, epoxy primer, 2 part urethane black topcoat, oven baked |
