Air Assist Detachable Gooseneck Trailer
35 ADG/40 ADG
EZ-2-LOAD, built to go to work
Let's face it, we're all working harder today than ever before. So why should you expect anything less from your equipment? Our thoughts exactly. That's why every EZ-2-LOAD trailer is designed to meet your unique needs. Our seasoned team of designers and engineers bring together the most innovative technology available to give you a different product, a product that delivers value to you each day, even in extreme environments.
Features and Benefits
- PATENTED AIR MECHANISM
- Unique air assisted gooseneck and main deck
- Best strength to weight ratio
- 3 year mainframe warranty
- Effortless, accelerated loading and unloading
- Gooseneck remains unblocked on the tractor while loading/unloading
- No messy hydraulics, no violent motion
- More relieable and safe
- More efficient and productive
- Lower operating costs
- Superior long-lasting finish
- Premium return on your investment
Available Options - 35 Ton
- Narrow gooseneck with flip extension
- Flip up 3rd axle
- Winches
- Wide load extremity lights
- LED light package - with 3 in a row
- LED 3-in-a-row taillights with inside light amber flashing
- Polished stainless rear trim package STD
- Aluminum wheel package (4 machined inside/4 polished outside)
- Removeable galvanized outriggers (14 per side)
- Aluminum pull outs including ramps (8500# Rated)
- Front mini ramps
- Side mount D-Rings (45 degree bend)
- Chain pullouts
- In floor D-Ring tie downs
- In floor tool box
35 ADG/40 ADG
Standard Specifications - Based on the 35 ADG RTAC Model
| Loaded Deck Height | 20 in. nominal loaded, adjustable +/- 2" |
|---|---|
| Ground Clearance | 6 in. nominal loaded, adjustable +/- 2" |
| Coupling | Weld in king pin location 15" |
| Coupler Plate | 1/2" hi-tensile, 48" optimum height |
| Swing Clearance | 76" norminal |
| Floor | 1 1/2" shiplapped softwood beams on main deck and on gooseneck 10 ga. formed deck plate over wheels |
| Main Frame | Fabricated 100 KSI top and bottom flanges (one piece, no splices) |
| Web | Hi-tensile |
| Cross Members | Hi-tensile 3" Jr. l-beam @ 16" OC
on gooseneck and over suspension Hi-tensile 8" & 6" Jr. l-Beam @ 12" OC on main deck |
| Side Rail | Fabricated 100 KSI 11 in. channel, incl. outrigger brackets 13 per side @ 24" |
| Suspension | 25,000 lb. underslung air ride, adjustable ride height +/- 2" Front axle wishbone suspension standard |
| Air Brake System | 25/1M ABS as per U.S. DOT/Transport Canada regulations |
| Brakes | 16 1/2" x 7", Q-type, non-asbestos |
| Axles | 25,000 lb. 5" round c/w big bearings |
| Cam Shafts | 28 spline enclosed |
| Slack Adjusters | Automatic, all axles |
| Brake Chambers | #3030, all exles |
| Hubs & Drums | 10 stud duralight hub, long stud cast drums |
| Front Connector | SAE J560 7 pin |
| Electrical System | Modular, vapor proof sealed beam lights, wired at rear for flip-up axle 4 Pin @ 4 corners for wide load lights; 7 pin @ rear of flip-axle |
| Lights | 3 in-a-row tailights per U.S. DOT/Transport Canada regulations |
| Finishing | Preparation by steel shot blasting, epoxy rich primer, 2 part urethane black topcoat, oven baked |
| Rims | 8.25 x 22.5 steel disc painted white |
| Mud Flaps | 2 Sets "EZ-2-Load" |
| Toolboxes | 1 Per Side, approx. 16" x 16" x 12 3/4", chain boxes in deck between main rails |
| Extra Plumbing/Wiring | For future flip up 3rd axle, emergency and service line, capped for future flip-ups |
